Solid MDF plywood furniture ATC cnc engraving machine

Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
Incoterm: FOB,CFR,CIF,EXW,FCA,CPT,CIP
Min. Order: 1 Set/Sets
Delivery Time: 20 Days

Basic Info


Model No.: YKS12-P

Type: Engraving Router

Feed Mode: Mechanical

Controlling Mode: CNC

Certification: CE, ISO, SGS, FDA

Customized: Customized

Condition: New

Color: Customized

After-sales Service Provided: Engineers Available To Service Machinery Oversea

X,Y Working Area: 1300mm*2500mm*200mm

Inverter: Delta/Sunfar Inverter

Contorl System: DSP/Official Ncstudio Control System/mach3

Table Surface: Vacuum Table

Transmission System: Hiwin/CSK Linear Bearings

Driver System: Japan YASKAWA Driver

Motor: Stepper/servo Motor

Spindle: 9.0KW Air Cooled Spindle

Transmission: X Y Axis With Rack And Pinion Drive Z Axis With Taiwan TBI Ball Screw


Additional Info


Packaging: Solid wood MDF plywood particle board panel furniture cnc engraving machine with Standard export wooden cases

Brand: YIHAI

Transportation: Ocean,Land,Air

Place of Origin: CHINA

Supply Ability: 200

Port: QINGDAO,TIANJIN,SHANGHAI


Product Description

Solid wood MDF plywood particle board panel furniture cnc engraving machine





FAQ


1.Question: How to buy? whats the main procedure?

First, we come to a final conclusion with agreement. May this step will cost more than months even years.
Scond, I prepare you the proforma invoice as we agreed.
Third, you bring the proforma invoce to the bank and do the advance payment transfer.
Fourth, after you showed me the bank slip, we factory start to produce your machine.
Fifth, machine finished within 13 working days, then we do the delivery and you finish the balance.
Sixth, You receive the machine in your port and pick it up to your workshop.


2. Question: What is the machine warranty? If any parts fault due to quality how can i do ?

Our machine are with 13 months qualtiy warranty. within 13 months, if any parts failed due to qualtiy, we will send you the replacement parts in no time and we provide 24 hours online technical support to you. Any time you meet any problem, just contact us.


3.Question: what is this machine used for? Do i need a cnc router?
If you are here I assume you are thinking about buying a CNC router or some other CNC machine. Without a doubt these are amazing machines that can improve your business or project tremendously. However, there are many other types of CNC robotics that may be better fitting for your application.
This machine can be used for furnitures engraving, room decorations, industrial equipment parts, music instrument, mold, art&craft, building models and advertisment industry.


4.Question: How can i find a machine which can satisfy my requirement within my budget? Which one is the right one for me?

First lets answer the following questions.

1)What type of materials do you plan to cut or engrave?
 ( Wood,Particle Board,Plastic,Foam,Composites,Glass,Aluminum )


2)What is the most complex design you foresee cutting?
The complexity of the design is another important considerations. What is meant by this is primarily the overall size and depth of cut per axis. Do you plan to use the machine for cutting, carving, drilling, or all of the above?


3)What kind of tolerances do you need to hold?
Now this is something that I am sure you have already considered but it is still worth discussing. A router is capable of leaving a near perfect finish while surfacing and overall the tolerances are good. A decent machine, you should expect a tolerance of .001" or better for a given distance.



Specifications

Number

Description

Parameter

1

X,Y,Z Working Area

1300x2500x200mm

2

X,Y,Z Traveling Positioning Accuracy

±0.03/200mm

3

X,Y,Z Repositioning Accuracy

±0.03mm

4

Table Surface

Vacuum and t-slot table (6 area)

5

Frame

frame steel (8mm),aging treatment

6

Gantry

steel structure(12mm)

7

X, Y Structure

Rack and Pinion Drive, Hiwin  Linear square rails

8

Z Structure

Hiwin Rail Linear square rails and TBI Ball Screw

9

Spindle Power

9.0KW spindle

10

Spindle Speed

0-24000RPM

11

Drive Motors

Servo motor

12

Working Voltage

AC380V/220V  50/60Hz,3PH

13

Command Language

G Code

14

Operating System

DSP/ Official Ncstudio controller

 (Options: German SIEMENS control system /

    Taiwan SYNTEC control system)



15

 Lubrucate

 Automaitic oil-filling

16

Flash Memory

128M(U Disk)

17

Collet

ER25

18

electric configuration

France schneider low voltage electric , emergency stop switch and Japan Omron limit switch

19

X,Y Resolution

<0.01mm

20

Software Compatibility

Artcam Software, (Option: Type3/UcancameV9 Software)

21

Running Environment  Temperature

0 - 45 Centigrade

22

Relative Humidity

30% - 75%

23

Optional Parts

WMH HMRON Helical Rack and Pinion Drive, Hiwin  Linear square rails

Dust Collector

Rotary System

YASKAWA/Panasonic servo/ DELTA Servo Motors

Solid wood board Cnc Engraving Machine

HTB1jj0tXjfguuRjy1ze7620KFXam
